CES-231210-18PM
-
BRVN:BRVN-CES-231210-18PM
-
MPN:CES-231210-18PM
-
MFR:
-
Description:24 X 13 MM, ENCLOSED, RECTANGULA
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
Import Tariff May Apply
Import Tariff may apply to this part if shipping to the United States.
-
- Description: 24 X 13 MM, ENCLOSED, RECTANGULA
- Manufacturer: CUI Devices
- Length: 0 mm
- Series: CES
- Product Status: Active
- Termination: Wire Leads with Connector
- Ingress Protection: -
- Type: General Purpose, Enclosure Included
- Size Dimension: 1.181" L x 0.512" W (30.00mm x 13.00mm)
- Ratings: -
- Technology: Magnetic
- Frequency Range: 680 Hz ~ 20 kHz
- Frequency Self Resonant: 850Hz
- Impedance: 8 Ohms
- Efficiency dBA: 88
- Efficiency Testing: 1W/100mm
- Efficiency Type: Sound Pressure Level (SPL)
- Power Rated: 1 W
- Power Max: 1.5 W
- Port Location: Top
- Shape: Rectangular
- Material Cone: Polyetheretherketone (PEEK)
- Material Magnet: Nd-Fe-B
- Height Seated Max: 0.433" (11.00mm)
-
- Datasheet: BRVN-CES-231210-18PM
