FCM-1A
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
Import Tariff May Apply
Import Tariff may apply to this part if shipping to the United States.
-
- Description: SMD FUSE - 2410, FAST ACTING 1A
- Manufacturer: OptiFuse
- Length: 0 mm
- Series: FCM
- Product Status: Active
- Voltage Rating - AC: 125 V
- Current Rating (Amps): 1:00 AM
- Approval Agency: CSA, cULus, PSE
- Package / Case: 2410 (6125 Metric)
- Operating Temperature: -55°C ~ 125°C
- Mounting Type: Surface Mount
- Size / Dimension: 0.240" L x 0.100" W x 0.100" H (6.10mm x 2.54mm x 2.54mm)
- Fuse Type: Board Mount (Cartridge Style Excluded)
- Voltage Rating - DC: 32 V
- Response Time: Fast Blow
- Breaking Capacity @ Rated Voltage: 50A AC, 300A DC
- Melting I²t: -
- Color: -
-
- Datasheet: BRVN-FCM-1A
