RD2-1A-DC-1-RL
-
BRVN:BRVN-RD2-1A-DC-1-RL
-
MPN:RD2-1A-DC-1-RL
-
MFR:
-
Description:OVAL-SHAPED OFF-ON RED LED
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
Packaging Type: Bulk
| Qty | Unit Price | Ext. Price |
|---|---|---|
| 1 | $2.50 | $2.50 |
Import Tariff May Apply
Import Tariff may apply to this part if shipping to the United States.
-
- Description: OVAL-SHAPED OFF-ON RED LED
- Manufacturer: Switch Components
- Length: 0 mm
- Series: RD2
- Product Status: Active
- Mounting Type: Panel Mount, Threaded Body with Nut
- Circuit: SPST
- Switch Function: On-Off
- Current Rating (Amps): 30A (DC)
- Voltage Rating - AC: -
- Voltage Rating - DC: 12 V
- Actuator Type: Concave (Curved) - Illuminated
- Illumination Type, Color: LED, Red
- Illumination Voltage (Nominal): 12 VDC
- Termination Style: Quick Connect - 0.250" (6.3mm)
- Panel Cutout Dimensions: Circular - 12.20mm Dia
- Ingress Protection: -
- Features: -
- Operating Temperature: -25°C ~ 85°C
- Color - Actuator/Cap: Black
- Actuator Marking: No Marking
-
- Datasheet: BRVN-RD2-1A-DC-1-RL
